型号 Type 名称 Name
KVV 铜芯聚氯乙烯绝缘及护套控制电缆
Cu conductor PVC indulated and sheathed control cable
KVV22 铜芯聚氯乙烯绝缘钢带铠装聚乙烯护套控制电缆
Cu conductor PVC insulated Steel tape armoured PVC sheathed control cable
KVVP2 铜芯聚氯乙烯绝缘聚氯乙烯护套铜带屏蔽控制电缆
Cu conductor PVC insulated and PVC sheathed copper tape screen control cable
KVV22 铜芯聚氯乙烯绝缘聚氯乙烯护套钢带屏铠装控制电缆
Cu conductor PVC insulated and PVC sheathed control cable with steel tape armmour
KVV32 铜芯聚氯乙烯绝缘聚氯乙烯护套钢丝铠装控制电缆
Copper conductor PVC insulated control withh fine steel wire arnour
KVVR 铜芯聚氯乙烯绝缘聚氯乙烯护套控制电缆
Copper conductor PVC insuated flexible control cable
KVVRP 铜芯聚氯乙烯绝缘聚氯乙烯护套编织蔽控制电缆
Copper conductor PVC insuated and sheathed flexible control cable with sheeted
ZR-KVV 铜芯聚氯乙烯绝缘聚氯乙烯护套阻燃控制电缆
Copper conductor PVC Insulated and sheathed flame retardant contro cable
ZR-KVVP 铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽阻燃阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant control cable with copper wire braid
ZR-KVVP2 铜芯聚氯乙烯绝缘聚氯乙烯护套钢带屏蔽阻燃阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant control cable with copper tape sheated
ZR-KVV22 铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant control cable with steel tape armour
ZR-KVV32 铜芯聚氯乙烯绝缘聚氯乙烯护套细铠装燃阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant control cable with copper wire braid
ZR-KVVR 铜芯聚氯乙烯绝缘聚氯乙烯护套阻燃阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant fixible control cable
ZR-KVVRP 铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽阻燃阻燃控制电缆
Copper conductor PVC insulated and sheathed flame retardant fixible control cable with sheild
聚氯乙烯绝缘控制电缆的综合数据
Composite data of pvc insulated control cable
KVV KVVP2 KVV22 450/750V GB 9330-88 芯数和导体标称截面 No of cores and nominal area of conductor(mm2) KVV KVVP2 KVV22
外径Max overall diameter(mm) 近似重量
Approx weight(kg/km) 外径Max overall diameter(mm) 近似重量
Approx weight(kg/km) 外径Max overall diameter(mm) 近似重量
Approx weight(kg/km)
3×0.75 3×1.0 3×1.5 3×2.5 8.4 8.8
9.8 11.0 83 93
119 163
3×4.0 3×6.0 3×10.0 12.5 14.0
18.5 222 310 508
4×0.75 4×1.0 4×1.5 4×2.5 9.0 9.4
10.5 12.0 101 114
148 205 10.0 10.5
11.5 14.0 134 150
192 256 17.0 412
4×4.0 4×6.0 4×10.0 14.0 15.0
20.0 289 392
640 15.0 16.0
21.5 346 456 726 18.5 19.0 25.0 496 619 956
5×0.75 5×1.0 5×1.5 5×2.5 9.6 10.0
11.5 14.0 112 128
170 256 11.0 11.0
12.50 15.0 151 169
218 313 18.0 463
5×4.0 5×6.0 5×10.0 15.0 16.5
22.5 434 470
802 16.0 17.5
23.5 406 541
897 19.5 21.5 26.5 567 741 1118
7×0.75 7×1.0 7×1.5 7×2.5 10.5 11.0
12.5 15.0 138 160
216 328 11.5 12.0
14.0 16.0 181 205
269 390 15.5 16.0
17.5 19.0 320 347
428 553
7×4.0 7×6.0 7×10.0 16.5 18.0
24.0 446 616
1057 17.5 19.0
25.0 516 694 1163 20.5 22.5 28.5 688 910 1400
8×0.75 8×1.0 8×1.5 8×2.5 11.5 12.0
14.5 16.5 156 181
260 370 12.5 13.5
15.5 17.5 202 230
317 438 16.5 17.0
18.5 21.0 348 380
471 610
8×4.0 8×6.0 8×10.0 18.0 20.0
27.0 507 723
1200 19.0 21.0 28.014.5
15.0 17.0 19.5 583 808 1315 23.0 24.5 31.5 788 1013 1571
10×0.75 10×1.0 10×1.5 10×2.5 12.5 14.0
16.0 18.5 190 240
320 460 14.5 15.0
17.0 19.5 244 297
388 541 18.0 18.5
20.5 23.0 408 446
559 761
10×4.0 10×6.0 10×10.0 20.5 22.5
30.5 657 899
1502 21.5 23.5
31.5 748 1000 1640 25.0 27.0 35.0 960 1230 1976
